SolarAlpha System

SolarAlpha Area / Flood Solar LED Lighting System

The SolarAlpha system is a complete system used for perimeters, parks, pathways, boat ramps, and area lighting projects. The Alpha flood fixture is an efficient budget friendly fixture and provides great light output with multiple distribution patterns. This fixture works best for applications with a mounting height of 15' to 25' providing even illumination for the specified area.
Specifications     Get A Quote

The SolarAlpha high powered LED solar lighting system comes complete with solar power assembly, fixture, bracket and all mounting hardware to attach to a pole. SEPCO can also provide a pole to meet wind load specifications.



The SolarAlpha solar power assembly ranges from 30 Watts to 550 Watts with the size of the battery assembly allowing for a minimum of five days autonomy. The solar power assembly is sized according to installation location and takes into consideration local weather conditions.



The Alpha fixture is a large flood style fixture and comes complete with LEDs and driver used to operate the fixture from the solar charged batteries. The SolarAlpha ranges from 15 to 55 Watts and comes with NEMA 2x2, 4x4, 5x5, 6x6 and 6x4 Distribution patterns, as well as 3K, 4K and 5K color temperatures.



The SolarAlpha's fixture uses the SH – Side of Pole Horn Bracket with a 10" upsweep to mount to a pole or wall. The fixture mounts below the solar panel at the required mounting height for the application.



The SolarAlpha system mounts to any round pole with a minimum diameter of 4", allowing the solar to face south while not restricting the direction of fixture installation. The system can be purchased complete with a pole for mounting the solar lighting system. Poles are available in aluminum, steel, fiberglass composite, or concrete and are anchor base or direct burial. All poles provided by SEPCO meet local AASHTO wind load requirements.
